ICP Sintered Brake Pad 300 Series
ICP Wind manufactures a comprehensive range of OEM and aftermarket-approved friction brake pads. Manufactured for all types of wind turbine brakes. Trusted by major wind turbine brands throughout the wind market.
300 series is a 22 button sintered friction brake pad formulated for Svendborg 300 series brakes. The sintered friction allows the brake to function more efficiently under extreme pressures.
- Size: 250 x 125 x 25.1 mm
- Friction material: FTL510 compares with Miba MD550
- OEM Ref: Svendborg: 490-0402-003, Siemens: A9B00080218, Vestas: 29087123
300 Series - Sintered Friction Pad without Lugs Replaces Svendborg 490-0402-803, Siemens: A9B00080218
FTL510 is a copper base sintered friction material, free of asbestos, lead, and zinc. FTL510 has a high friction coefficient and offers excellent anti-fade and wear properties. It can be used at all duty levels and will offer consistent behaviour throughout. Suitable for brakes and clutches in usual mechanical engineering, especially heavy mechanical load. The material is unsuitable for working in oil.
The sintered friction material allows brakes to function more efficiently under extreme heat. Drastically reducing the risk of any cracks, splitting and disintegration when performing under extreme pressure.
| Svendborg | 490-0402-003 |
|---|---|
| Svendborg | 490-0402-803 |
| Svendborg | 492-0201- 801 |
| Material | Sintered |
|---|---|
| OEM Replacement | Nordex, Siemens, Svendborg |
| Wind Turbine Brand | DE WIND, Fuhrländer , GE, Nordex, Siemens |
| Wind Turbine Model | D4, MD70, MD77, FL1000, FL600, 600KW, N54, SWT 2.3 |
| Brake Type | BSAK300 |
| Number Of Buttons | 22 |
| Friction Coefficient | 0.4 - 0.5 |
| OEM Numbers | Svendborg: 490-0402-003, Svendborg: 490-0402-803, Siemens: A9B00080218 |
| Size | 250 x 125 x 24 mm |
